600 * 320 * 600mm Bomb Disposal Robot With 15hrs Hearing Device Working Time

L4 Interception robot

The purpose of the interception robot is to replace the close contact with explosives, detect the electronic and mechanical timing detonation devices hidden under various packaging covers, and ensure the personal safety of the detonators. The robot is compact in size and easy to enter the places where the human body is inconvenient to enter and exit.

Features

1, can achieve 360 degree rotation.

2. equipped with image system, 360 degree monitoring without dead angle, can observe the surrounding situation from time to time for the operator to control the robot;

3, the electronic hearing device has the function of lifting.

4. The vehicle is small and light.

The listening device can move up and down.

Video surveillance

Cable transmission available

Robots equipped with lights.

Specifications

Robot main parameters:

1, camera pixels: 1080P

2, size: 600*320*600mm

3, weight: 15.5KG

4, data transmission control: 50m

5, picture transmission control: 50m

6, voltage: 12V

7, working time: less than 1h

8, the characteristics of electronic hearing devices:

(1), working hours: 15 hours;

(2) maximum detection distance:

Maximum detection distance of mechanical timer: < 600mm

Maximum detection distance of electronic timer: < 20mm

(3), working temperature: -15 C - 45 C;

(4), size: 210*100*100mm.

(4) extension cable: 50 meters.

9. hearing devices lifting height: 0-150MM

Remote controller parameters

1, size: 355*270*70mm (including antenna)

2, weight: 2KG

3, voltage: 12V

4, display size: 4.3 inches.

5, working time: less than 1h

System composition:

L4 interception robot 1

remote controls 1

Robot charger 1

Remote control charger 1

Hearing device extend cable 1roll

Earphones 1
